REINFORCEMENT DETAILING
ACI Chapter25
Check reinforcement development lengths, lap splices and hooks under ACI 318 Chapter 25, in SI and US units.
Outputs
Calculation report, PDF export and Excel export for engineering review.
INDUSTRIAL STRUCTURAL ENGINEERING
Focused tools.
Clear engineering workflows.
Practical tools for structural engineering calculations and load combination workflows.
Try Free BetaFree Guest Beta
THE FIRST TWO APPLICATIONS
Built around practical engineering tasks.
LOAD COMBINATION WORKFLOW
Load Combination Manager
Prepare, generate and review load combinations, then export them for a controlled engineering workflow.
Outputs
Combination preview and Excel export for engineering review.
APPLICATION GUIDES
Know the scope before you start.
ACI Chapter25 Application guide
Use case
Review reinforcement development, lap splice and hook lengths under ACI 318 Chapter 25.
Inputs
SI or US units, ACI edition, material properties, reinforcement geometry and detailing conditions.
Outputs
Calculation report, PDF export and Excel export for engineering review.
Limitations
Results depend on the selected edition and input conditions. Project applicability and final detailing require engineer review.
Getting started
Select units and edition, enter the reinforcement details, then review the report and exports.
Load Combination Manager Application guide
Use case
Prepare, generate and review load combinations for a controlled engineering workflow.
Inputs
Project load definitions, selected combination profile and supported source files.
Outputs
Combination preview and Excel export for engineering review.
Limitations
SAP2000 transfer uses a Windows Agent on the user’s computer, not the website server. Live transfer is not publicly available.
Getting started
Define the project basis and loads, prepare the combinations, then review the preview and export.
IN DEVELOPMENT
Dyke / Bund Wall & Retaining Wall
Liquid-containment and earth-retaining design workflows.
Tank Foundation
Foundation workflows for industrial storage tanks.
Structural Foundation
Foundation workflows for industrial steel structures.
Planned / Coming Soon — Not Available in Beta. No public execution or release dates announced.
Engineering Assistant Output — Subject to Engineer Review and Approval.
Check inputs, assumptions, code applicability and results before project use. These tools support engineering judgement and do not replace the responsible engineer.CONTACT
